Important highlights
Presenting our new premium high efficiency 80 PLUS certified Gaming Power Supply, ZEB-PGP600W.This Product is a 12V 45A Single rail Power supply that comes with extra long cables. The Power supply is designed with active power factor correction for better efficiency. Various features such as built in protection, 2 x PCIe connectors, 6 x SATA connectors & more gives you the tool to build ultimate gaming experience.

|
Specifications
| Active PFCs |
Yes |
|
| Input voltage | 230v | |
| Input current | 4A | |
| Fan type | Oil bearing | |
| Power good signal |
≥300ms |
|
| Hold up time | ≥18mss | |
| Efficiency |
20% loading ≥ 82%, 50% loading ≥ 85%, 100% loading ≥ 82% |
|
| MTBF |
20000 hours | |
| Protections |
OVP / OPP / SCP / UVP |
|
| Operating temp |
45ºc | |
| Product Dimension (W x D x H) |
150 x 140 x 85 mm (W x D x H) | |
| Box dimension (W x D x H) |
300 x 250 x 112 mm (W x D x H) | |
| Weight |
1.6 kg | |
| Country of Origin | China |
