	7" Large Screen
	IP65-rated Waterproofing for Outdoor Unit
	Door Lock Release
	IR Night Vision
	Do not disturb mode
	30 Melodic Tones
	Enables Video Monitoring (for up to 1 minute)
	Two-way Talkback
	Connect Upto 2 Outdoor Unit

	Outdoor Unit
	Image Sensor Config.	2MP 1/3" CMOS
	Image Resolution	960 x 576
	Frame Rate	25 FPS
	Lens	1/3" @F2.94mm
	Night Vision	up to 5m
	Outdoor Unit Net. Weight	160g
	Outdoor Unit Dimension (W x D x H)	5 x 2.8 x 13.6 cm
	Motion Detection	No
	Voice Messages	NA
	Surface Mount	Yes
	Adjustable Microphone and Speaker Volume	Yes
	LED for Night Vision	IR LED
	Angular Bracket	Yes
	Wifi Enabled	No
	Housing	Plastic
	IP level	IP65
	View Angle	120° wide angle
	Indoor Unit
	Screen Size	17.78 cm
	Screen Resolution	1024x600 pixel
	Brightness Setting	Adjustable
	Contrast Setting	Adjustable
	Image Adjustment	yes
	Colour Setting	Adjustable
	Volume Adjustment	Yes
	Night Vision	IR Night vision
	Talkback Type	Yes
	Door Lock Release	Yes
	External SD Card Support	No
	Image Storage	No
	Image Storage Capacity	NA
	Video Storage	No
	Video Storage Capacity	NA
	Recorded Video Length	NA
	Indoor Monitors	1 Indoor unit
	Input power	DC 14.5V
	Melody	30 melody options
	Digital Photo Frame	No
	SDRAM	4MB DDR2 (Built-in CPU)
	Effective Area	Horizontal 120°，Diagonal 145°,Vertical 65°
	Microphone	-42dB
	Relative Humidity	< 90%
	Input Voltage	DC 14.5V, 1A max.
	Power Consumption	Static State ≤ 3W , Working State ≤ 10W
	Operating Temparature	-20 °C to 50 °C
	Indoor Unit Net. Weight	285g(With Mounting Bracket)
	Indoor Unit Dimension (W x D x H)	18.3 x 2.37 x 13.1 cm
	Package Content
	QR code Guide	1 U
	Indoor Unit	1 U
	Outdoor Unit	1 U
	Mounting Kit	1 Set
	Connectors Kit	1 Set
	Power Adaptor	1 U

Video Door Phone
